• Recessed, Surface, Wall Mounted and Suspended linear lights
• Standard modular lengths with Fast-Track lead times
• Direct or Direct-Indirect lighting with a choice of Medium/High Power, Lens Louver and Asymmetric Wallwash LED
• Compact fixed output drivers, or a range of dimming options including DALI, 1-10V, Switch-Dim or Casambi control
• Available on request - corner modules, curves, sensors, Integrated emergency conversions, IP54 rated and more
• White, Black, Silver, Graphite, Copper and Champagne finish

Product Options
Dimensions (mm):	Direct-Indirect: 75 (W) x 75 (H)*
Cut-out (mm):	N/A
Lifetime:	50,000 hrs
Mounting Type:	Wall Mounted
Finish:	White, Black, Silver, Champagne Gold, Copper, Graphite.
Emergency:	DALI or Standard emergency conversion
Weight:	-
Lighting Options
Light Source:	Medium Power, High Power
Driver:	Fixed Output, 1-10V, DALI, Touch Dim, Casambi control
Colour Temperature:	2200K, 2700K, 3000K, 3500K, 4000K, 6500K
Beam Angle:	(Direct only 100% or Direct-Indirect 45/55%)
Diffuser:	Opal, MPO, Ambient, Asymmetric Wallwash (Lens Louver on request)
Operating Voltage:	230V
IP Rating:	IP20
CRI:	CRI80, CRI90
Delivered Lumens (lm):	from 1120lm to 10220lm
Power Consumption (W):	from 16W to 88W
Efficiency (lm/W):	up to 118lm/W
Optional Extras:	Integrated Track, sensors, spotlights and 90° corners on request

Additional Information
*Luminaire dimensions may vary with mounting type.
