Introducing our latest innovation, the New Quad luminaire, embodying a harmonious blend of professionalism and designer aesthetics. Designed in compliance with the Zhaga standards, this cutting-edge luminaire boasts new LED boards that deliver a minimum Colour Rendering Index (CRI) of 90, while simultaneously ensuring exceptional efficiency.

The New Quad luminaire represents a complete and cohesive product family, offering an extensive array of customizable options. Our standard modules are conveniently available in practical lengths of 500mm, 1000mm, 1500mm, 2000mm, and 2500mm, while our made-to-measure alternatives allow for precise customization down to the millimetre.

With a strong commitment to sustainability, the New Quad luminaire is proudly manufactured in Oxfordshire, with a strong focus on circularity. The entire product family has achieved full TM66 scores, and our aluminium materials are composed of 75% recycled content sourced from UK recycling centres and off cuts.

Setting industry benchmarks, our Optics options are unparalleled. The bespoke diffuse opal design, meticulously crafted for the New Quad luminaire, guarantees optimal lighting performance. Furthermore, our innovative MPO diffuser employs cone technology to achieve a visually comfortable, low-glare illumination, avoiding the distracting effects often associated with conventional MPOs.

Great design lies at the core of the New Quad luminaire, with each component meticulously engineered to create a captivating linear lighting solution. The slender edges, measuring as thin as 1.4mm, bestow an elegant and nearly imperceptible profile, underscoring our unwavering commitment to exceptional design principles.

In addition to our standard offerings, we take pride in catering to bespoke design requirements and seamlessly integrating our luminaires into comprehensive lighting systems.

Key Features:
• Minimum 90 CRI for superior colour rendering and high efficiency
• Compatible with DALI, Switching, or Casambi control systems
• Integrated 3-hour emergency conversions available for added safety
• Available in standard finishes of Matt White, Matt Black, and Anodized Aluminium, with an extensive range of additional options including RAL and acoustic finishes
• UGR compliant, ensuring optimal visual comfort

Experience the transformative power of the New Quad luminaire, where professionalism and designer excellence converge in perfect harmony.

Product Options
Dimensions (mm):	60mm (W) x 85mm (H)
Cut-out (mm):	60mm (W) x 85mm (H)
Lifetime:	up to 100,000 h
Mounting Type:	Surface Mounted
Finish:	White fine texture (RAL9010), Black fine texture (RAL 9005) , Anodised Aluminium and bespoke finishes available.
Emergency:	DALI or Standard 3 hour emergency conversion (300Lm OUTPUT))
Weight:	2.0 kg per Metre
Lighting Options
Light Source:	90 CRI
Driver:	Fixed Output, DALI Dimmable, Casambi control
Colour Temperature:	2700K, 3000K, 4000K, 5000K
Beam Angle:	Lens Louvre 30°, 50° and 80° / Wall washer / Direct diffused light
Diffuser:	OPAL , MPO cone and Dark diffusers
Operating Voltage:	230V
IP Rating:	IP20 (IP rated up to IP65 on request)
CRI:	90 Min
Delivered Lumens (lm):	up to 3000 lm/M Bespoke lumen outputs available on request
Power Consumption (W):	up to 21.0 W/M
Efficiency (lm/W):	up to 139 lm/W
Optional Extras:	integrated track, PIR sensors
